Active Area1209.6x 680.4mm Brightness 320cd/m2LCD Interactive Touch Screen

Ask Lasest Price
Brand Name :	YODA
Model Number :	Y55LVW-P03
Certification :	ROHS,CE,FCC
Price :	Negotiable
Payment Terms :	L/C, T/T, Western Union, MoneyGram
Supply Ability :	5000PCS/per mouth
Delivery Time :	Within 7~15 days after order upon payment receiving

Add to Cart

Product Details
Company Profile

Active Area1209.6x 680.4mm Brightness 320cd/m2LCD Interactive Touch Screen

Indoor LCD Video Wall Display TFT Seamless Video Wall Monitors

Details of product:

1.Display quality ranges from the simplest monochrome character graphics to video displays of various specifications with high resolution, high color fidelity, high brightness, high contrast and high response speed.
2.View Angle is 178 degrees (up and down)/178 degrees (left/right).
3.Sensitive touch box, click < 8ms, continuous writing < 3ms.
4.Including dual system configuration and conference software, not only for teaching but also for conferences.
5.The appearance of the whole machine is composed of aluminum alloy two-color front shell and plastic back shell.
6.Waterproof screen, extend the service life of the product.
7.Operating temperature can be controlled at -20°C~+50°C.
8.Support a variety of languages, such as English, German, Italian, Spanish and so on, you can choose according to your preferences.

Display Information
Screen Size	55inch	65inch	75inch	86inch
Panel Type	a-Si TFT-LCD	a-Si TFT-LCD	a-Si TFT-LCD	a-Si TFT-LCD
Aspect Ratio	16:9	16:9	16:9	16:9
Resolution	3840*2160P	3840*2160P	3840*2160P	3840*2160P
Viewing Angle	89/89/89/89	89/89/89/89	89/89/89/89	89/89/89/89
Brightness	320cd/m2	350cd/m2	350cd/m2	350cd/m2
Active Area	1209.6x 680.4mm	1428.48x803.52mm	1649.664x927.936mm	1913x1084mm
Contrast Ratio	4000:1	4000:1	1200:1	1200:1
Response Time	8ms	8ms	8ms	8ms
Display Color	8 bit 1.67M	8 bit 1.67M	10 bit 1.07B	10 bit 1.07B
Field Frequency	60Hz	60Hz	60Hz	60Hz
Service Lifetime	≥60,000 hours	≥60,000 hours	≥60,000 hours	≥60,000 hours
Touch System
Sensing Type	Infrared System (Multi 10 point touch)
Response Time	6ms
Connection	Full-speed USB (Driver free)
Surface Protection	Tempered Glass with 4mm thickness Standard
Graphic card	Intel HD Graphics, Supports 1080P, H264, 3D play
Bluetooth	Bluetooth4.0
Speaker	15W x2
Network	WIFI/ RJ45
Port	USB2.02/ USB3.02/ HDMI out1/ VGA out1/ RJ45 Lan port1/ Speaker out1/ Mic in*1
Built-in Dual System Android and Windows
Operating System	Android 6.0
CPU	Quad Core Cortex A7 1.8 GHZ
RAM	DDR3 2G
ROM	32G
SD card slot	Support MAX 128G
Port	RJ451, VGA OUT1, VGA IN1, VGA AUDIO IN1, Ypbpr IN1, AV IN2, AV OUT1, Earphone1, TV1, Spdif OUT1, HDMI IN2, USB2.02, SD card slot1, Touch USB2, MIC*1
Languages	English, French, Germany, Arabic, Italian, Japanese,Korean, Russian, Spanish, etc
Power
Power Supply	96~264V AC, 50/60Hz
Power Consumption	220W~500W
Operating Temperature	0℃~50℃
Storage Temperature	-10℃~70℃
Supplied Accessories	AC Power Cable, 4-in-1 Remote Control, Touch Pens*2, whiteboard software
Ambient Conditions
Dimension (LWH)	1290.5817.699.3mm	1516.3947.196mm	1737.71072.6103mm	1991.1x1212.6x125.6mm
Package LWH	1427963232mm	16461062230mm	18601230260mm	2136*1370x280mm
Net weight	40KG	50KG	68KG	76KG

Real-picture

Product's details

Application

FAQ

Q:How long is the warranty period of the product?
A:The regular warranty period is 1 year. If you need a longer warranty, please contact our sales engineer.

Q:When can I get the quotation?
A:We usually quote within 12 hours after we got your inquiry.
If it is very urgent,please call us or contact us via email,Skype or WhatsApp.

Q:May I buy samples from you?
A:Yes!You are welcome to place sample order to test our superior quality and service.

Q:Does your company support customization?
A:Yes,we support customization.Customizable festures include,appearance,camera,brightness,logo,NFC,scanner,printer,discrete graphics,
wheels,color,etc.

Q:What is the minimum order quantity?
A:The MOQ is 1. Welcome to order samples. Quality is our confidence.

Q:What is the shipping package?
A:Strong bubble bag+carton+wooden case/3mm Honeycomb box. Transport breakage rate is less than 1%.
