Indoor LCD Video Wall Display TFT Seamless Video Wall Monitors
Details of product:
1.Display quality ranges from the simplest monochrome character
graphics to video displays of various specifications with high
resolution, high color fidelity, high brightness, high contrast and
high response speed.
2.Appearance is classic type, Stents shapes, Chassis or Other
customized.
3.The voltage is 3.3v, 5V, 12V for customers to choose.
4.The machine itself comes with 5G hotspot.
5.With teleconference function, can support 20 people at the same
time,And mobile phone terminal and computer terminal can be carried
out.
6.Support a variety of languages, such as English, German, Italian,
Spanish and so on, you can choose according to your preferences.
7.The appearance design is very thin, the touch use effect is good.
8.The appearance of the whole machine is composed of aluminum alloy
two-color front shell and plastic back shell.
| Display Information | | Screen Size | 55inch | 65inch | 75inch | 86inch | | Panel Type | a-Si TFT-LCD | a-Si TFT-LCD | a-Si TFT-LCD | a-Si TFT-LCD | | Aspect Ratio | 16:9 | 16:9 | 16:9 | 16:9 | | Resolution | 3840*2160P | 3840*2160P | 3840*2160P | 3840*2160P | | Viewing Angle | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 | | Brightness | 320cd/m2 | 350cd/m2 | 350cd/m2 | 350cd/m2 | | Active Area | 1209.6x 680.4mm | 1428.48x803.52mm | 1649.664x927.936mm | 1913x1084mm | | Contrast Ratio | 4000:1 | 4000:1 | 1200:1 | 1200:1 | | Response Time | 8ms | 8ms | 8ms | 8ms | | Display Color | 8 bit 1.67M | 8 bit 1.67M | 10 bit 1.07B | 10 bit 1.07B | | Field Frequency | 60Hz | 60Hz | 60Hz | 60Hz | | Service Lifetime | ≥60,000 hours | ≥60,000 hours | ≥60,000 hours | ≥60,000 hours | | Touch System | | Sensing Type | Infrared System (Multi 10 point touch) | | Response Time | 6ms | | Connection | Full-speed USB (Driver free) | | Surface Protection | Tempered Glass with 4mm thickness Standard | | Graphic card | Intel HD Graphics, Supports 1080P, H264, 3D play | | Bluetooth | Bluetooth4.0 | | Speaker | 15W x2 | | Network | WIFI/ RJ45 | | Port | USB2.0*2/ USB3.0*2/ HDMI out*1/ VGA out*1/ RJ45 Lan port*1/ Speaker
out*1/ Mic in*1 | | Built-in Dual System Android and Windows | | Operating System | Android6.0 | | CPU | Quad Core Cortex A7 1.8 GHZ | | RAM | DDR3 2G | | ROM | 32G | | SD card slot | Support MAX 128G | | Port | RJ45*1, VGA OUT*1, VGA IN*1, VGA AUDIO IN*1, Ypbpr IN*1, AV IN*2,
AV OUT*1, Earphone*1, TV*1, Spdif OUT*1, HDMI IN*2, USB2.0*2, SD
card slot*1, Touch USB*2, MIC*1 | | Languages | English, French, Germany, Arabic, Italian, Japanese,Korean,
Russian, Spanish, etc | | Power | | Power Supply | 96~264V AC, 50/60Hz | | Power Consumption | 220W~500W | | Operating Temperature | 0℃~50℃ | | Storage Temperature | -10℃~70℃ | | Supplied Accessories | AC Power Cable, 4-in-1 Remote Control, Touch Pens*2, whiteboard
software | | Ambient Conditions | | Dimension (L*W*H) | 1290.5*817.6*99.3mm | 1516.3*947.1*96mm | 1737.7*1072.6*103mm | 1991.1x1212.6x125.6mm | | Package L*W*H | 1427*963*232mm | 1646*1062*230mm | 1860*1230*260mm | 2136*1370x280mm | | Net weight | 40KG | 50KG | 68KG | 76KG |
|
Real-picture
Product's details
Application
FAQ
Q:What is the company's business philosophy?
A:Quality first, service first.
Q:Are you a factory or a trading company?
A:We are a OEM/ODM factory.
Q:How long is the warranty period of the product?
A:The regular warranty period is 1 year. If you need a longer
warranty, please contact our sales engineer.
Q:How to ensure product quality?
A:Triple detection:
1) Raw material testing.
2) Detection after assembly is completed.
3) Detection after 48 hours of running.
Q:What is the price? And do you provide customization, OEM or ODM
service?
A:Our price is depend on the functions, sizes, designs, quantities,
applications etc, please send the inquiry and tell us more about
your requirements and project then enable us to quote the price
accordingly. We have structure engineer teamwhich can provide
customization,OEM or ODM service.
Q:When can I get the quotation?
A:We usually quote within 12 hours after we got your inquiry.
If it is very urgent,please call us or contact us via email,Skype
or WhatsApp.
