Details of product:
1. Support the same screen different display, multi-screen display
2. High brightness, good picture quality and high definition.
3. Boot can set automatic loop playback, whole loop playback,
single loop playback and other multi-function Settings.
4. The surface adopts toughened glass design, physical toughened
Morse level 7 explosion-proof.
5. Automatically generate and play flow log file filing function (easy
for advertisers to inquire records) without any hand Dynamic operation (selection).
6. The motherboard adopts the RK3288 Cortex-A17 quad-core
application processor with the main frequency up to 1.8GHz and fast
computing speed.
7. Super Mali-T764 GPU, support 4K, H.265 hardware decoding.
8. Support Chinese and English rolling subtitles.External subtitles
(optional).
Appearance | Surface | Tempered Glass |
Colour | High grade metal enamel shell, black and silver frame |
Materials | Aluminum profile frame, a cold rolled sheet |
LCD Panel | Size | 32" |
Brand | BOE |
Resolution | 1920*1080 |
Active Area | 698.4(H) ×392.85(V) |
Brightness | 400cd/m2 |
Viewing Angle | 89/89/89/89 |
Contrast Ratio | 1200:1 |
Color Depth | 16.7M |
Scanning Frequency | 60Hz |
Backlight Type | WLED |
Configuration | System | Windows i3,4+500G(HDD) |
Interface | Built-in speaker and camera,Support
Ethernet,Wi-Fi,RS-232,MIPI,RJ45,USB etc. |
Loudspeaker | 8W*2 |
Power Supply | Input Power | AC 110-240V, 50/60HZ |
Work Environment | Work Temperature | 0℃—45℃ |
Work Humidity | 20%-80%RH |
Store Humidity | 20%-80%RH |
Other | Dimensions | 730mm*430mm*50mm |
Carton Size | 813X512X56mm |
Net Weight | 10.05 KG |
Gross Weight | 11.55KG |
Installs Way | Wall-mounted |
The Real-picture of the digital
The Product's details of the digital menu board
The Application of the digital menu board
FAQ
Q:What is your MOQ?
A:Any quantity is acceptable for your order. And the price is
negotiable for large quantity.
Q:What brand of screen is used?
A:All our screen adopt A+ LG panel , Durable Aluminum Frame Design
with Tempered Glass Surface.
Q: What is the price? And do you provide customization, OEM or ODM
service?
A:Our price is depend on the functions, sizes, designs, quantities,
applications etc, please send the inquiry and tell us more about
your requirements and project then enable us to quote the price
accordingly. We have structure engineer teamwhich can provide
customization,OEM or ODM service.
Q:Do you have any After-Sales service?
A:Yes!Our products have professional After-sales Department.
If you have any technical problem or question with the
goods,welcome to contact us directly.
Q: What's the shipment terms and delivery time of your company?
A:The goods can be shipped by courier,by air or by sea. Depend on
quantity and customer's requirement.
